QG Series Air Stream Dryer
>> Principle
It is equipped with fan that has the function of
dispersing. So it is suitable for heat sensitive raw material
specially. The impeller of fan with high speed can crush
the wet and blocked raw material till dispersing. During the
period of dispersing, it is stirring and mixed. Then the raw
material and air are flowing in parallel. It's applicable for
drying raw materials that are blocked cake but only surface
moisture less than 40%. If the amount to be treated is
large or the moisture required of finished products is less
than 60%, two grades drying can be used. If the moisture
of raw materials is between 40% and 60%, the feeder
is difficulty. It is necessary to adapt mixer. Through the
method of mixing dry raw material into it to decrease the
moisture of raw material. At this time, the total output of
dryer will be decrease greatly. It is not suitable in economy.
Therefore customer should remove the moisture using
machinery method (centrifugal or press) so as to decrease
its moisture as possible in order to guarantee the drying
operation can be carried out freely.
>> Applications
The equipment can meet different needs of raw materials. Besides the
mentioned raw materials in basic model, there are methaqualon, A.B.C
intermediate, ABS resin, white carbon black, tea, catalyst of oxalic acid,
promote agent m, d.m, catalyst, deposited carbon powder, N-acetylsulfanilyl
chloride, p-aminosalicylic acid, p-phthalic acid, diethyl aniline,
titanium dioxide, active carbon, sodium fluosilicate, ammonium sulphate,
powder of silicon glue, synthesis resin, calcium polvsilicate, PP resin,
aureomycin, sodium polaysilicate, oral glucose, sodium polysilicate, mine
of sulphate, mine of phosphorus, BB blue, melting phosphorus fertilizer,
tetracycline, ferric oxide, calcium carbonate, titanium/ferric mine, copper
mine, powder of white potato, tail coal, stearate, zein, medicine, medical
agent, ferric oxide, lees so on.
>> Technical parameters
spec |
Moisture to be evaporated(kg/h) |
Power(kw) |
Occupied area(m2) |
Height(m) |
| QG50 |
50 |
7 |
20 |
14 |
| QG100 |
100 |
13 |
32 |
14 |
| QG200* |
200 |
21 |
40 |
15 |
| QG250 |
250 |
24 |
64 |
15 |
| QG500 |
500 |
43 |
96 |
18 |
| QG1000* |
1000 |
100 |
120 |
18 |
| QG1500* |
1500 |
150 |
200 |
20 |
